TUYA Smart Life APP WIFI&GSM Wireless Home Security Burglar Alarm System Camera
Intercom monitoring throughout the whole process，remote yelling to terrorize thieves
Support 9 languages switched freely
5 preset alarm calls,no missing any alarm information

PIR detector PA-92R
Wireless PIR detector： 1. Adopts CMOS low-power consumption microprocessor 2. Low power consumption,the battery with a longer life 3. Built-in Millions of codes 4. Transfer digital wireless signals 5. Low voltage alert function 6. All-around automatic temperature compensation 7. Intelligent logic analysis to avoid fault alarm 8. Anti white light 9. Anti high frequency interference



Wireless WIFI GSM Alarm Host
| Size |
185mm x 125mm x 14.7mm / 7.28" x 4.92" x 0.57" |
| Screen |
2.4-inch TFT Large Digital Display Screen |
| Function |
Daily Date/Clock Indication |
| Operating System with Multitasking Design |
| Automatic Alarm Indicates Offline |
| APP Function |
Support APP Remote Arm/disarm |
| parameter setting and accessory management |
| Learning/Storage Location |
Support up to 100 learning and storage locations for Remote Control and Wireless detection. |
| Record Function |
Record 20-second alarm Voice |
| if alarm occurs, the alarm host will dial preset number and play the record voice |
| Timer Function |
Can set automatic arm/disarm time according to your own routine time,avoiding repeated operation or miss arm/disarm |
| Support Timing Arm and Disarm |
| Network |
Support WIFI/GSM/GPRS Intranet Alarm System |
| Support Different Alarm Channels (APP Push / SMS / Voice monitoring / intrannet center Alarm, to ensure the alarm performance stable and reliable) |
| Telephone Function |
Support 5 groups preset alarm phone number, SMS on/off and dial on/off can be set respectively |
| Support SMS Alarm/Disarm and Voice Alarm/Disarm |
| Defense Zone Support |
Support gate, SOS, bedroom, window, balcony, perimeter, smoke, gas, carbon monxide, water leaking ect. |
| Daily Operation |
Remote Control |
| Keyboard |
| Remote SMS |
| Mobile phone APP |
| GPRS Alarm Center |
| Language |
Support English, Chinese, German Three Language Setting |
| Input voltage |
DC5V |
| Working Current |
<120mA |
| Standby current |
<80uA |
| Siren output |
<500mA |
| Wireless frequency |
433MHz |
| Wireless Coding |
EV1527 |
| WIFI Standard |
IEEE 802.11b/g/n Wireless Standard |
| Back up Battery |
3.7v/500mAh Lithium Battery |
|
|
Wireless PIR Motion Detector
Working Voltage：2x AAA Battery)
(Does not including)
Working Current：<=25mA
Static Current：<= 15uA
Detecting Distant：8-12m
(Depending on different house situation)
Emission Distance：>=80m (Open Area )
Detect Angle：120°
Installation Height：Recommend 1.8m-2.2m
Operation Temperature：-10℃-55℃
Wireless Frequency：433MH
|
|
|
Wireless Door/Window Gap Detectors
Voltage：3V Button Battery
(Does not includepasting)
Under Voltage Monitoring：7.5 V+/-0.5V
Static Current：<=10uA
Triggering Distance：25-35mm
Emission Current：<=15mA
Emission Distance：>=120 m (Open area)
Emission Frequency：433MHz
Working Temperature：-10℃ ~50 ℃
Convenient Function: Simply put it any please you want in your home :)
( such as door, window, drawer, wardrobe, bath etc)
When someone pass it by, DG-HOSA will ring
|
|
|
Remote Control Fob
To control this system including arm/disarm/partial arm, and emergency help.
The wireless remote set includes a 4-key remote and a wireless receiver module board Working Voltage: 12V
Working Current: ≤3mA (5.0V DC)
Modulation Mode: ASK
Sensitivity: -105dBm (50Ω) |
|
